Description
Main
| range of product | Modicon X80 |
|---|---|
| Accessory / separate part type | Rack |
| number of slots | 8 bus X + Ethernet |
|---|---|
| product compatibility | I/O module BMX processor Specific application module BMXCPS power supply BME processor |
| power consumption in W | 211 mW 3.3 V DC 3.9 W 24 V DC |
| electrical connection | 1 connector (XBE) expansion module |
| fixing mode | By 4 screws – diameter: 4.32…6.35 mm, mounting on panel By 4 M6 screws, mounting on plate By clips, mounting on 35 mm symmetrical DIN rail |
| current consumption | 64 mA at 3.3 V DC 164 mA at 24 V DC |
| MTBF reliability | 1700000 H |
| net weight | 1.06 kg |
| IP degree of protection | IP20 |
|---|---|
| ambient air temperature for operation | 0…60 °C |
| relative humidity | 5…95 % without condensation |
| directives | 2014/35/EU – low voltage directive 2014/30/EU – electromagnetic compatibility |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 1.052 kg |
| Package 1 Height | 6.6 cm |
| Package 1 width | 15.3 cm |
| Package 1 Length | 45.5 cm |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 9 |
| Package 2 Weight | 10.28 kg |
| Package 2 Height | 30.0 cm |
| Package 2 width | 40.0 cm |
| Package 2 Length | 60.0 cm |
