Description
| range of product | Modicon Quantum automation platform |
|---|---|
| product or component type | Processor |
| software name | ProWORX 32 Concept |
| processor name | 80186 |
| mathematical coprocessor | Without |
| clock frequency | 20 MHz |
|---|---|
| memory description | Internal RAM 368 kB |
| exact time for 1 Kinstruction | 0.3…1.4 ms LL984 |
| watchdog timer | 250 ms |
| clock drift | +/-8 s/day at 0…60 °C |
| I/O words | 30 I/32 O distributed 64 I/64 O max local 64 I/64 O remote |
| I/O words/network | 500 I/500 O distributed |
| drops/network | 63 distributed |
| number of drops | 31 remote |
| number of network | 2 remote 3 distributed |
| battery type | Lithium 7 µA 210 µA |
| battery capacity | 1.2 Ah |
| battery life | 10 year(s) |
| number of port | 1 Modbus RS232 1 Modbus Plus |
| communication module processor capacity | 2 NOM, NOE, CR, NMS |
| switch function | Without key switch |
| marking | CE |
| bus current requirement | 790 mA |
| module format | Standard |
| net weight | 0.3 kg |
| product certifications | FM Class 1 Division 2 cUL |
|---|---|
| standards | UL 508 CSA C22.2 No 142 |
| resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2 |
| resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| ambient air temperature for operation | 0…60 °C |
| ambient air temperature for storage | -40…85 °C |
| relative humidity | 95 % without condensation |
| operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.0 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31.0 cm |
| Package 1 Weight | 514.0 g |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 21 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 40.0 cm |
| Package 2 Length | 60.0 cm |
| Package 2 Weight | 11.827 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 7 |
| Package 3 Height | 30.0 cm |
| Package 3 Width | 30.0 cm |
| Package 3 Length | 40.0 cm |
| Package 3 Weight | 4.113 kg |
