Description
M1/M1E processor adaptor – 1 Ethernet, 1 I/O bus – 50 MHz
| range of product |
Modicon Momentum automation platform
|
|
|---|---|---|
| product or component type |
M1/M1E processor adaptor
|
|
| concept |
Transparent Ready
|
|
| level or class |
Class B10
|
|
| software designation |
Concept version V2.6
Modsoft version >= V2.5 ProWORX NxT version V2.0 ProWORX 32 |
|
| communication port protocol |
Ethernet
|
|
| processor name |
X 86 based (INTEL, AMD) IEC executive
|
|
| clock frequency |
50 MHz
|
| web services |
Rack viewer
Web page loader software tool Web page loader Data editor |
|
|---|---|---|
| Ethernet service |
I/O scanning
Modbus TCP messaging |
|
| discrete I/O processor capacity |
8192 I/8192 O
|
|
| memory type |
1 MB flash
544 kB RAM |
|
| memory description |
Program memory 18 kB LL984
Program memory 200 kB IEC Data 24 kB |
|
| material |
Lexan
|
|
| word length |
16 bit
|
|
| [Us] rated supply voltage |
5.0 V DC +/-5 %
|
|
| supply |
By Momentum I/O base
|
|
| exact time for 1 Kinstruction |
1 ms
|
|
| register I/O processor capacity |
26048 I/26048 O
|
|
| I/O limit processor capacity |
8192 bits max
|
|
| I/O words/drop |
128 I/O Concept
80 I/O ProWORX |
|
| number of port |
1 I/O bus
1 Ethernet |
|
| marking |
CE
|
|
| net weight |
0.042 kg
|
| protective treatment |
TC
|
|
|---|---|---|
| ambient air temperature for operation |
0…60 °C
|
|
| ambient air temperature for storage |
-40…85 °C
|
|
| relative humidity |
5…96 % without condensation
|
|
| operating altitude |
2000 m
|
|
| shock resistance |
<= 15 gn peak 11 ms half sine wave acceleration
|
|
| vibration resistance |
1 gn
0.75 mm d.a |
|
| product certifications |
UL
Nema type 250 CUL FM Class 1 Division 2 |
