Description
| Range of product | Twido |
|---|---|
| Product or component type | Discrete input module |
| Discrete input number | 16 |
| Discrete input voltage | 24 V |
| discrete input voltage type | DC |
| I/O connection | HE-10 connector |
| Number of common point | 1 |
| Input voltage limits | 20.4…28.8 V |
|---|---|
| Discrete input logic | Sink or source |
| Discrete input current | 5 mA |
| Input impedance | 4.4 kOhm |
| Filter time | 8 ms at state 0 8 ms at state 1 |
| Insulation between channel and internal logic | 1500 Vrms for 1 min (by photocoupler) |
| Current consumption | 35 mA at 5 V DC at state 1 for all inputs 5 mA at 5 V DC at state 0 for all inputs |
| Marking | CE |
| Net weight | 0.065 kg |
| product certifications | CSA UL |
|---|---|
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0…55 °C |
| Ambient air temperature for storage | -25…70 °C |
